Overview – 8-Port Gen 2 RFID Reader
This 8-Port smart UHF RFID reader embedded with an Impinj R2000 "Indy" reader chip features carrier cancellation technology and provides unmatched read
accuracy, reliability and range. The reader is compliant with EPC Class 1 Gen 2 Dense Reader mode (DRM) ISO 18000-6C standard. This RFID reader is equipped
with 8 SMA RF antenna ports that support up to 8 mono-static antennas or 4 pairs of bi-static antennas. It provides GPIO with 8 inputs and 8 outputs, an
ample 1G memory, and data communications through 10/100 Base-T RJ45, USB and RS232 ports. These powerful features provide support for the richest and most
demanding enterprise applications.
Key Features – 8-Port Gen 2 RFID Reader
- Intel ATOM N270 1.6 GHz CPU with 1 GB DRAM 4 GB Flash memory to run complex RFID applications
- Embedded with an Impinj "Indy" R2000 Reader chipset
- Compliant with EPC C1 Gen 2 and ISO 18000-6C standards
- Supports EPC Dense Reader Mode(DRM)
- Long read range, RF output power up to 32 dbm
- Supports 8 mono-static antenna with 8 reading points or 4 bi-static antennas with 4 reading points
- Microsoft XP embedded, hosts applications written in Java, Java Script or C# .Net
- Directly monitors and controls presence detectors
Technical Specifications – 8-Port Gen 2 RFID Reader
RF
|
Frequency
| US: 902 MHz to 928 MHz
EU: 865 MHz to 868 MHz
|
Demodulation
| ASK or PSK
|
Modulation Depth
| 90% nominal
|
Data
Encoding
| FM0 or Miller code
|
Bit Rate
| Uplink data rates of up to 640 Kbps
|
TX Output
power
| 5 dBm to 32dBm in 1 dB step
|
Antenna Type
| 8 Port Mono-static or 4 Port Bi-static
|
Antenna connector
| 8 SMA connectors
|
Compliance
|
RFID Protocol
| EPC DRM Yes (with DRM Filter) Switchable
|
EPC DRM
| DRM Filter, Switchable
|
EMC
certification
| FCC 47 CFG Ch.1 Part 15 (US)
ETSI EN 302 208-1 (V1.1.1) (EU)
|
Certification
| CE/FCC
Class A, UL, CCC
|
Communication
|
USB
| 4 × USB, Rev 2.0 compliant
|
Ethernet
| 10/100 Base-T (RJ-45)
|
COM Port
| RS-232 (DB9 F)
|
GPIO
| 8 digital input, 8 digital output
|
Expansion
| SD Card Reader port
Expansion
port for Bluetooth, WLAN, GPRS/3G, WiMax
|
System Architecture
|
Processor
| Intel ATOM
N270 1.6 GHz
|
Chipset
| PHY: Impinj R2000
MAC: ATMEL AT91SAM7S-256
|
System Memory
| 1 GB DDR2 SDRAM expandable to 2 GB
|
Internal Storage
| 4 GB Compact Flash expandable to 8 GB
|
Display
| VGA 640 × 480 up to 1600 × 1200
|
Keyboard / Mouse
| USB port for Keyboard/Mouse
|
Software
|
Operating System
| Windows XP / Linux
|
Software SDK
| Java, Java Script or C# .Net APIs
|
General Characteristics
|
Dimensions
| 265 mm × 194 mm × 71 mm
|
Weight
| 2.5 kg
|
Base Material
| Die-cast aluminum
|
Mounting
| Wall mounting, vertical placement
|
Power Input
| DC 10-30 V, 2.55 A, 30 W
with 3-pin connector
|
Power Consumption
| 30 W (Typical), Isolation
|
Humidity
| 10%-85%
non-condensing
|
Operating Temperature
| 0 °C to 55 °C at 85% RH
|
Storage Temperature
| -20 °C to 85 °C at 85% RH
|
